ISOSCAN® EDS150

  • Automatic insulation fault location
  • Application main circuits
  • 6 measuring channels
  • Integrated measuring current transformers
  • Universal system concept

The insulation fault locator EDS150 in conjunction with the ISOMETER®, are designed for insulation fault location in unearthed power supplies (IT systems). The locating current pulse generated by the ISOMETER® are detected using the integrated measuring current transformers and evaluated by the insulation fault locators. The integration of six measuring current transformers in an EDS150 permits all current-carrying conductors of an outgoing line to be routed through. The response time for an alarm message inclusively indication on the respective display device is max. 8 s (e.g. MK2430).

A total of 88 EDS150 devices can be connected via an RS-485 interface (BMS protocol). Hence, up to 528 circuits can be monitored. Activities on the BMS bus are indicated by an alarm LED.

ISOSCAN® EDS150/EDS151
ISOSCAN® EDS150/EDS151
  • Automatic insulation fault location
  • Application main circuits
  • 6 measuring channels
  • Integrated measuring current transformers
  • Universal system concept

The insulation fault locator EDS150 in conjunction with the ISOMETER®, are designed for insulation fault location in unearthed power supplies (IT systems). The locating current pulse generated by the ISOMETER® are detected using the integrated measuring current transformers and evaluated by the insulation fault locators. The integration of six measuring current transformers in an EDS150 permits all current-carrying conductors of an outgoing line to be routed through. The response time for an alarm message inclusively indication on the respective display device is max. 8 s (e.g. MK2430).

A total of 88 EDS150 devices can be connected via an RS-485 interface (BMS protocol). Hence, up to 528 circuits can be monitored. Activities on the BMS bus are indicated by an alarm LED.

Caratteristiche

  • Insulation fault location in AC, AC/DC and DC IT systems
  • 6 measuring channels with measuring current transformer per EDS150
  • Up to 528 measuring channels can be combined by the BMS bus in the IT system being monitored: 88 x 6 measuring channels
  • Response sensitivity EDS150: 5 mA
  • A response time of up to 8 s in the AC system acc. to IEC 61557-9
  • RS-485 interface with BMS protocol
  • BMS address range 3…90
  • Cyclical self test

Applicazioni

  • Insulation fault location in AC, AC/DC and DC IT systems
  • DC main circuits in industrial plants, power stations and ships

ISOSCAN® EDS150 Variante/i

TypeSupply voltage*Art. No.
EDS150AC 17…24 V, 50…60Hz/DC 14…28 VB91080103

* Absolute values of the voltage range

Accessori opzionali per ISOSCAN® EDS150

TypeSupply voltageOutput voltageArt. No.Note
AN410AC 90…264 V, 47…63Hz*
DC 120…370 V*		DC 24 V, 420 mAB924209Supplies up to six EDS151
AN450AC 230 V, 50…60 HzAC 20 V, 500 mAB924201Supplies up to six EDS151
AN450-133AC 127 V, 50…60 HzAC 20 V, 500 mAB924203Supplies up to six EDS151

* Absolute values of the voltage range
